General Specification:
- Voltage Range: 12 & 24v dc (240v also available)
- Power Output Range: 40 to 100 watts
- Speed Range: up to 10,000 rpm
- Operational Temperature: -20°C to +40°C
- Insulation Class: F (Consult us for class B)
- Bearing Type: High quality ball bearing
- Housing Type: Closed (ventilated also available)
Definition of Part number:
63 | ZYT | 95 | 12V | X |
Frame size | Brushed dc motor | Motor length | Voltage | External code |
Specifications:
| Model | Voltage | Rated Power | Rated Speed | Rated Torque | Rated Current | No load Speed | Length |
|---|---|---|---|---|---|---|---|
| Units | V | W | rpm | mNm | A | rpm | mm |
| 63ZYT95-12V | 12 | 44.5 | 3100 | 137 | 5.2 | 3600 | 95 |
| 63ZYT95-24V | 24 | 48.4 | 3300 | 140 | 2.7 | 3600 | 95 |
| 63ZYT95-40V | 40 | 48.7 | 3500 | 133 | 1.7 | 3800 | 95 |
| 63ZYT125-12V | 12 | 75.4 | 3000 | 240 | 8.7 | 3500 | 125 |
| 63ZYT125-24V | 24 | 94.7 | 3350 | 270 | 4.9 | 3650 | 125 |
| 63ZYT125-40V | 40 | 97.5 | 3450 | 270 | 3 | 3600 | 125 |
Outline:
Customization:
 |  |  |  | |  |
| Shaft | Encoder | Brake | Connector | Pulley | Gearbox |
| Item | Description |
|---|---|
| Shaft Extensions | Motors can be configured with single or double-ended shafts, manufactured to your specific length. |
| Encoder Options | We offer integration with various encoders to meet specific resolution and application needs. |
| Brake Options | Motors can be equipped with an optional brake, available with or without a manual hand release. |
| Cable Harnesses | Custom cable harnesses, with or without connectors, are available upon request. |
| Pulleys & Pinion Gears | Pulleys or pinion gears can be supplied and mounted to your specifications. |
| Gearbox Integration | Most motors can be paired with various gearbox types, including planetary, worm wheel, and parallel shaft gearboxes. |
